2019 POWERSCREEN 1000 MAXTRAK

2019 POWERSCREEN 1000 MAXTRAK
$575,000 (USD)
Washington
Description
Cone crushers are highly effective at using compression to crush material into a consistent product. For this reason, cone crushers are the most commonly used crushing plant for secondary and tertiary crushing stages in both the aggregate and recycling industries. When used correctly, cones will have a far lower operating cost than an impactor and produce less fines. The Powerscreen range of mobile cone crushers excel in a variety of applications from hard and abrasive rock to softer and more friable rock. The range uses advanced Automax® crusher technology to provide high volumes of excellently shaped product.
The high performance Powerscreen® 1000 Maxtrak portable rock crusher has been designed for direct feed applications without pre-screening on clean rock. At the heart of the Maxtrak is the Automax cone crusher with hydraulic setting, tramp release, and unblocking system. Its unique crushing action provides excellent capacity, high reduction, and good product cubicity for the production of high quality aggregate and sub-base materials.
Features and Benefits
- Output Potential: up to 230 tph (253 US tph)
- Renowned Automax® crusher technology
- Accepts clean all in feed
- Excellent product shape
- High reduction ratio
- Cone feed box level control to maintain choke feeding
- Hydraulic crusher setting
- Cone overload protection
- Heavy duty chassis and track frame
- Metal detector
- Dust suppression system
- Economical to operate with a highly fuel efficient direct drive system
- Fitted with Powerscreen Pulse Telematics system
Options
- Concaves: extra coarse, medium coarse, coarse, Autosand®
- Short throw eccentric
- Feed hopper extension plates
- Product conveyor belt weigher
- Electric refuelling pump
- Electric water pump
- Radio remote control
- Camera and viewing screen
Specifications
Manufacturer | POWERSCREEN |
Model | 1000 MAXTRAK |
Year | 2019 |
Condition | Used |
Serial Number | PID10MXTKOMK19238 |
Stock Number | 1000MT-1 |
Output Potential | 230tph (253 US tph)* / 230tph (253 US tph)* |
Transport Dimensions | Width: 9'2" Length: 47'11" Height: 11'4" / Width: 2.8m Length: 14.6m Height: 3.45m |
Working Dimensions | Width: 11'4" Length: 47'11" Height: 13'5" / Width: 3.46m Length: 14.6m Height: 4.1m |
Weight | Tier 3: 67,108lbs Tier 4: 70,151lbs / Tier 3: 30,440kgs Tier 4: 31,820kg |
CSS Range | Min: 0.7" Max: 1.6" / Min: 18mm Max: 38mm |
